트랙션 인버터

Traction Inverter IconIn the high-voltage electrical system of a car, truck or bus, the traction inverter sits between the high voltage system battery and the electric motor. It converts the HV system DC voltage into 3 AC output phases to drive the motor.

The combination of the inverter and motor is a key component in an EV, determining the performance, driving feel and dynamics. The range of a vehicle is directly related to the efficiency of the traction inverter and motor across the driving profile, including acceleration, steady state and energy recovery into the battery via regenerative braking.

Power Integrations offers automotive qualified gate drivers and power supply ICs for the traction inverter which increase efficiency while saving space and cost and meeting functional safety. Reinforced isolation, extended creepage distance packages meet latest requirements for vehicles moving to 800 V architectures.

레퍼런스 디자인

Additional Documents
디자인
제품
DER-952Q - 86 W Power Supply for 800 V Bus Using InnoSwitch3-AQ (1700 V SiC Switch)
Product InnoSwitch3-AQ
RDHP-2256Q - Bitstream Error Emulator for SCALE EV Gate Driver Board
Product 2SP0215F2Q0C
DER-965Q - 10 W Non-Isolated Buck Power Supply for 400 V BEV Systems using Automotive-Qualified LinkSwitch-TN2Q
Product LinkSwitch-TN2Q
DER-948Q - 35 W Power Supply for 800 V Bus with 30-1000 VDC Input and 15 V Output Using InnoSwitch3-AQ (1700 V SiC Switch)
Product InnoSwitch3-AQ
RDR-707Q - 9.75 W Non-Isolated Buck Power Supply using Automotive-Qualified LinkSwitch-TN2Q
Product LinkSwitch-TN2Q
DER-956Q - 13 W Dual Output Power Supply for 800 V Bus Using InnoSwitch3-AQ (1700 V SiC Switch)
Product InnoSwitch3-AQ
DER-946Q - 10 W, 7.5 V Output Power Supply for 800 V Bus Using InnoSwitch3-AQ (1700 V SiC Switch)
Product InnoSwitch3-AQ
RDHP-2250Q - Adapter Board for Operation of SCALE EV Gate-Driver Board
Product 2SP0215F2Q0C
DER-913Q - 35 W Power Supply for 800 V Bus with 40-1000 VDC Input Using InnoSwitch3-AQ (1700 V SiC Switch)
Product InnoSwitch3-AQ
DER-926Q - 13 W Triple-Output Power Supply for 400 V Bus with 40-530 VDC Input Using InnoSwitch3-AQ
Product InnoSwitch3-AQ
DER-719Q - 2.7 W StackFET Buck Power Supply using Automotive-Qualified LinkSwitch-TN2Q
Product LinkSwitch-TN2Q
RDR-840Q - 30 W Power Supply for 400 V Bus with 30-550 VDC Input Using InnoSwitch3-AQ
Product InnoSwitch3-AQ
DER-844Q - 4.5 W Non-Isolated Buck Power Supply using Automotive-Qualified LinkSwitch-TN2Q
Product LinkSwitch-TN2Q

관련 상품

Related Products
제품
데이터 시트
토폴로지
전압 레벨
설명
Topology Integrated Half-Bridge
Power Level
Description

최대 1200V의 Infineon™ EconoDUAL™ 17mm IGBT 전원 모듈용 ASIL 인증 플러그 앤 플레이 듀얼 채널 게이트 드라이버 보드

Topology Flyback, Secondary Side - FluxLink Regulated
Power Level 100 W
Description

750V, 900 V & 1700 V MOSFET 및 FluxLink 피드백이 통합된 자동차 애플리케이션용 CV/CC QR 플라이백 스위처 IC

Topology Non-Isolated Flyback, Buck/Boost/Buck-Boost
Power Level 850 mA
Description

적은 부품 수의 파워 서플라이를 위한 시스템 레벨 보호 기능이 통합된 자동차용 에너지 고효율 스위처 IC
