RDK-706 - 26.5 W Dual-Output Isolated Flyback Power Supply for Appliances Using TOPSwitch-JX
26.5 W dual-output isolated flyback power supply for appliances using TOPSwitch-JX
アプリケーション
仕様
Associated Product Numbers
TOP267VG
Design Type
Reference Design Reports (RDR)
トポロジー
Flyback
RoHS?
Yes
Vout 1
12.00 V
Vout 2
5.00 V
Vin (min)
90
Vin (max)
265
P (NoLoad)
90.00 mW
CV/CC
CV/CC
Efficiency
86.40%
EU ErP Compliant?
Yes
絶縁型?
Yes
Number of outputs
2
出力
26.50 W
OVP?
Yes
Associated Parts
TOP267VG
Gerber File
rdr-706_gerber.zip
